Coax Bulk
123-401-50
FF401 bulk RF coaxial cable
Cellular DAS · Public-safety LTE · 4G/5G FR1 (sub-3 GHz)
5089 · Available
Stock to 28 days
$5.02
Premier · per ea
Sign in to see your contracted tier pricing — or call (949) 888-5548 for volume pricing.
Details
FF401 is a 50-ohm RF coaxial cable engineered for low-PIM, durable cellular feeder runs. Rated to 6 GHz.
Construction: Silver-plated copper inner conductor, Taped PTFE dielectric, Silver-plated copper braid outer conductor (shield), White FEP (Plenum-Compliant, Non-UL-Cert jacket.
Operating range -55 to 150 °C. Sold by the foot from continuous reels; cut to length on order.
Construction: Silver-plated copper inner conductor, Taped PTFE dielectric, Silver-plated copper braid outer conductor (shield), White FEP (Plenum-Compliant, Non-UL-Cert jacket.
Operating range -55 to 150 °C. Sold by the foot from continuous reels; cut to length on order.
Why this part
FF401 50-ohm RF coaxial cable, engineered for low-PIM, durable RF interconnect.
1. Electrical Characteristics
Required to build assembly| Nominal Impedance (Ω) | 50 |
|---|---|
| Frequency Range | DC – 6 GHz |
| — Cable Attenuation Chart (Standard Test Frequencies) — | |
| Cable Attenuation @ 600 MHz (dB/100 ft) | 5.60 |
| Cable Attenuation @ 1.9 GHz (dB/100 ft) | 10.45 |
| Cable Attenuation @ 2.6 GHz (dB/100 ft) | 12.45 |
| Cable Attenuation @ 3.5 GHz (dB/100 ft) | 14.73 |
| Cable Attenuation @ 6 GHz (dB/100 ft) | 20.12 |
| Velocity of Propagation (Vp) (%) | 72 |
| Dielectric Constant (εr) | 1.93 (derived from Vp) |
| Time Delay (ns/ft) | 1.41 (derived) |
| Capacitance (pF/ft) | 28.2 |
| Shielding Effectiveness (dB) | ≥ 80 |
| Proof Voltage (V) | 1000 |
| Average Power Handling @ 2 GHz (W) | 50 |
| PIM Rating (dBc) | -160 |
2. Construction & Dimensions
| — Identification — | |
|---|---|
| Cable Family / Trim Code | FF401 |
| Commercial Name | FF401 |
| Cable OD — Overall | 0.265 in / 6.73 mm |
| Cable Weight | 0.078 lb/ft / 116 g/m |
| — Inner Conductor — | |
| Inner Conductor — Material | Silver-plated copper |
| Inner Conductor — Diameter (in) | 0.0641 |
| Inner Conductor — Construction | Solid |
| — Dielectric — | |
| Dielectric — Material | Taped PTFE |
| Dielectric — Diameter (in) | 0.2080 |
| Dielectric — Construction | Tape-wound |
| — Outer Conductor / Shield — | |
| Outer Conductor — Type | Braid |
| Outer Conductor — Material | Silver-plated copper braid |
| Outer Conductor — Diameter (in) | 0.2180 |
| Overall Braid — Diameter (over braid) (in) | 0.2400 |
| — Jacket — | |
| Jacket — Material | White FEP (Plenum-Compliant, Non-UL-Cert |
| Jacket — Color | White |
3. Mechanical Performance
| Bend Radius — Single / Installation | 0.75 in / 19.1 mm |
|---|---|
| Bend Radius — Repeated / Dynamic | 0.75 in / 19.1 mm |
| Cable Pull Tensile | 222 N / 50 lb |
| Cold Bend Temperature (operating min) (°C) | -55 |
4. Environment
| Operating Temperature Range (°C) | -55 to +150 |
|---|---|
| Flame Rating | CMP (plenum) — FEP (derived from jacket) |
| UV / Outdoor Rating | Outdoor (FEP is UV-stable) (derived) |
References
| Alternate Part Number | TFT-401 |
|---|---|
| Legacy Part Number | 123-14FF |
