Fiber Optic Assemblies
123-430402JB4FD250F-P
LC/UPC-Optitap (SC/APC) 2F Duplex, Single Mode, 250ft
Fiber Optic Assemblies
Stock to 28 days
$367.00
Premier · per ea
Log in to see your company’s contract price — or call (949) 888-5548 for volume pricing.
Details
The 123-430402JB4FD250F-P is a stocked inventory item in the Fiber Optic Assemblies category: LC/UPC-Optitap (SC/APC) 2F Duplex, Single Mode, 250ft.
Available to order from 123eWireless — contact us for current pricing, availability, and lead time.
Available to order from 123eWireless — contact us for current pricing, availability, and lead time.
Why this part
LC/UPC-Optitap (SC/APC) 2F Duplex, Single Mode, 250ft — stocked and ready to ship from 123eWireless.
Physical Specifications
| Length | 250ft |
|---|---|
| Connector A | LC/UPC Duplex |
| Connector B | Optitap (SC/APC) Duplex |
| Fiber Count | 2 |
| Breakout Length Side A | 6IN |
| Breakout Length Side B | 12IN |
| Furcation | 2 mm |
| Outer Diameter | 5.4mm |
| Fiber Type | SMF-28® Ultra |
| Jacket Color | Black |
| Jacket Material | OFNR, I/O |
Cross Reference
| Alternative To | ANDFHBDW-H2Q22, DX OptiTap/LC, FHBDW-H2Q22, 430402JB4FD250F-P |
|---|
Attenuation
| Attenuation @ 1550nm | 0.25 dB/km |
|---|---|
| Attenuation @ 1310nm | 0.40 dB/km |
Optical Specifications
| Insertion Loss | < 0.5 dB |
|---|---|
| Return Loss | >50 dB |
Environmental Specifications
| Operating Temperature | -20°C to +70°C |
|---|---|
| Varmint Rating | None |
References
| Alternate Part Number | 430402JB4FD250F-P |
|---|
