Fiber Optic Assemblies
123-F4X2-1A477-05M-005
Armored LC/UPC-LC/UPC 2F, Single Mode I/O LSZH, 5M
Armored LC/UPC-LC/UPC Indoor/Outdoor 5.0mm Armored LSZH SM 2 Fiber Round Distribution with 6IN breakouts on each end.
Stock to 28 days
$54.00
Premier · per ea
Sign in to see your contracted tier pricing — or call (949) 888-5548 for volume pricing.
Details
Armored LC/UPC-LC/UPC Indoor/Outdoor 5.0mm Armored LSZH SM 2 Fiber Round Distribution with 6IN breakouts on each end.
Physical Specifications
| Length | 5M |
|---|---|
| Connector A | LC/UPC Duplex |
| Connector B | LC/UPC Duplex |
| Fiber Count | 2 |
| Breakout Length Side A | 6IN |
| Breakout Length Side B | 6IN |
| Furcation | 2 mm |
| Outer Diameter | 5.0 mm ±0.2 |
| Fiber Type | G652D MM62.5/125 G657 |
| Jacket Color | Black |
| Jacket Material | LSZH, I/O |
Cross Reference
| Alternative To | DFJ-2S123 |
|---|
Attenuation
| Attenuation @ 1550nm | 0.25 dB/km |
|---|---|
| Attenuation @ 1310nm | 0.40 dB/km |
Optical Specifications
| Insertion Loss | < 0.5 dB |
|---|---|
| Return Loss | >50 dB |
Environmental Specifications
| Operating Temperature | -20°C to +70°C |
|---|---|
| Varmint Rating | 1.0mm stainless steel armored tube |
References
| Alternate Part Number | DFJ-2S123 |
|---|
