RF Terminator
123-HFT200-P
4.3-10 Female 200W Low PIM RF load terminator, 50 Ω
RF system load termination · Splitter/coupler unused-port termination
Stock to 28 days
$720.18
Premier · per ea
Sign in to see your contracted tier pricing — or call (949) 888-5548 for volume pricing.
Details
The 123-HFT200-P is a 200 watt, 50-ohm RF load terminator with a 4.3-10 Female Straight connector. Operates DC to 6 GHz.
Engineered for dissipation across the operating band with stable impedance match. VSWR ≤ 1.35 across the operating band. Low-PIM verified per assembly.
Used to terminate unused RF ports on splitters, couplers, and DAS combiners during test and live operation. Environmental: operating temperature -22F to 149F.
Engineered for dissipation across the operating band with stable impedance match. VSWR ≤ 1.35 across the operating band. Low-PIM verified per assembly.
Used to terminate unused RF ports on splitters, couplers, and DAS combiners during test and live operation. Environmental: operating temperature -22F to 149F.
Why this part
Engineered 200 watt 50-ohm 4.3-10 Female Straight RF load terminator — stable impedance match for production and field service.
Physical Specifications
| Connector A | 4.3-10 |
|---|---|
| Gender | Female |
Electrical Specifications
Required to build assembly| Average Power (W) | 200 |
|---|---|
| Frequency Range | DC–6 GHz |
| Impedance (Ω) | 50 |
| VSWR ≤ 6 GHz | ≤ 1.35 |
| PIM (IM3) (dBc) | -156 |
Environmental Specifications
| Operating Temperature | -22F to 149F |
|---|
References
| Legacy Part Number | 123-HFT200-160 |
|---|
