Coax Bulk
123-195-50
Low-Loss 195 bulk RF coaxial cable
Public-safety LTE · 4G/5G FR1 (sub-3 GHz) · 5G mid-band
546 · Available
Stock to 28 days
$7.27
Premier · per ea
Sign in to see your contracted tier pricing — or call (949) 888-5548 for volume pricing.
Details
Low-Loss 195 is a 50-ohm RF coaxial cable engineered for reliable, durable RF interconnect. Rated to 8 GHz.
Construction: Solid BC inner conductor, Foam PE dielectric, Aluminum Tape outer conductor (shield), PE jacket.
Operating range -40 to 85 °C. Sold by the foot from continuous reels; cut to length on order.
Construction: Solid BC inner conductor, Foam PE dielectric, Aluminum Tape outer conductor (shield), PE jacket.
Operating range -40 to 85 °C. Sold by the foot from continuous reels; cut to length on order.
Why this part
Low-Loss 195 50-ohm RF coaxial cable, engineered for durable, reliable RF interconnect.
1. Electrical Characteristics
Required to build assembly| Nominal Impedance (Ω) | 50 |
|---|---|
| Frequency Range | DC – 8 GHz |
| — Cable Attenuation Chart (Standard Test Frequencies) — | |
| Cable Attenuation @ 600 MHz (dB/100 ft) | 9.02 |
| Cable Attenuation @ 1.9 GHz (dB/100 ft) | 16.45 |
| Cable Attenuation @ 2.6 GHz (dB/100 ft) | 19.42 |
| Cable Attenuation @ 3.5 GHz (dB/100 ft) | 22.76 |
| Cable Attenuation @ 6 GHz (dB/100 ft) | 30.46 |
| Velocity of Propagation (Vp) (%) | 80 |
| Dielectric Constant (εr) | 1.56 |
| Time Delay (ns/ft) | 1.27 (derived) |
| Capacitance (pF/ft) | 25.4 |
| Inductance (µH/ft) | 0.064 |
| DC Resistance — Inner Conductor (Ω/1000 ft) | 7.60 |
| DC Resistance — Outer Conductor (Ω/1000 ft) | 4.90 |
| Shielding Effectiveness (dB) | ≥ 95 |
| Proof Voltage (V) | 1000 |
| Peak Power Handling (kW) | 2.5 |
| Average Power Handling @ 2 GHz (W) | 70 |
| PIM Rating (dBc) |
2. Construction & Dimensions
| — Identification — | |
|---|---|
| Cable Family / Trim Code | LL195 |
| Commercial Name | Low-Loss 195 |
| Cable OD — Overall | 0.195 in / 4.95 mm |
| Cable Weight | 0.021 lb/ft / 31 g/m |
| — Inner Conductor — | |
| Inner Conductor — Material | Solid BC |
| Inner Conductor — Diameter (in) | 0.0370 |
| Inner Conductor — Construction | Solid |
| — Dielectric — | |
| Dielectric — Material | Foam PE |
| Dielectric — Diameter (in) | 0.1100 |
| Dielectric — Construction | Foam |
| — Outer Conductor / Shield — | |
| Outer Conductor — Type | Braid + Foil |
| Outer Conductor — Material | Aluminum Tape (foil) + Tinned Copper (braid) |
| Outer Conductor — Diameter (in) | 0.1160 |
| Overall Braid — Diameter (over braid) (in) | 0.1390 |
| — Jacket — | |
| Jacket — Material | PE |
| Jacket — Color | Black (default) |
3. Mechanical Performance
| Bend Radius — Single / Installation | 0.50 in / 12.7 mm |
|---|---|
| Bend Radius — Repeated / Dynamic | 2.00 in / 50.8 mm |
| Bending Moment | 0.27 Nm / 0.20 ft-lb |
| Cable Pull Tensile | 178 N / 40 lb |
| Flat Plate Crush | 15 lb/in / 26.3 N/cm |
| Cold Bend Temperature (operating min) (°C) | -40 |
4. Environment
| Operating Temperature Range (°C) | -40 to +85 |
|---|---|
| Storage Temperature Range (°C) | -70 to +85 |
| Installation Temperature Range (°C) | -40 to +60 |
| Flame Rating | CMG / outdoor — PE (derived from jacket) |
References
| Legacy Part Number | 123-RF195 |
|---|
